34
Corrections
1.1 Make sure the power cord is plugged into
the wall outlet and the back of the unit or
restore power to the wall outlet.
1.2 Reset the circuit breaker.
1.3 Reset the cut out thermostat.
1.4 Have a technician replace the “Power” light.
1.5 Have a technician check out the unit.
2.1 Have a technician replace the “Heat” light.
3.1 Turn the multi-purpose valve to the STE
position
3.2 Close the door tightly
3.3 Replace or readjust the door switch activator.
When adjusting – unscrew the by ¼ turn
until the door microswitch is pushed in
when the door is closed.
3.4 Turn the timer on
3.5 Have a technician check out the unit.
Possible cause check-up and tests
1.1 the unit is not plugged in or the wall outlet
has no power
1.2 Circuit breaker is tripped
1.3 Cut out thermostat is tripped
1.4 Turn the multi-purpose valve to the
“Exh/Dry” position and set the timer to 15
minutes.
If the “Dry” light is on then the “Power”
light is burned out. When finished turn the
timer back to 0 minutes
1.5 If the “Dry” light does not come on then
there is an internal electrical problem.
2.1 The “Heat” light is burned out.
3.1 the multi-purpose valve is not in the STE
position.
3.2 the door is not closed tightly.
3.3 The door switch activator is missing or not
adjusted correctly.
3.4 The timer is off.
3.5 There is an internal problem.
10 TROUBLESHOOTING
This troubleshooting section is for use by the Operator of the autoclave. If a problem develops that is not covered in this
section then a qualified technician needs to be called. Please call your dealer or Tuttnauer USA Co.
Symptom
1. Power indicator
light does not light
up when the Start /
Stop switch is in
the start position.
2. Heat indicator light
does not light up at
the beginning of the
sterile cycle. The
Power light is on and
the unit does heat up.
3. Heat indicator light
does not light up at
the beginning of the
sterile cycle. The
Power light is on and
the unit does NOT
heat up.
