Field Production Monitor
24
[1] USER ASPECT
07 OTHER FUNCTIONS
USER ASPECT
WIDTH +1920
HEIGHT +1080
• Used to adjust the Width /Height display ratio.
1. Select [Aspect] mode in the OSD menu by pressing the function button on the right top of the monitor
to activate the [USER ASPECT] mode.
2. After the activation, press the Knob to begin controlling. Adjust the ratio using the knob.
- Adjust the ratio using the Knob.
- Control range for width: 0~1920.
- Control range for height : 0~1080.
- The size-adjusted picture always stays in the center of the screen.
- The size can be adjustable with 2 increment and decrement.
# To adjust the 16:9 aspect ratio of 1920X1080 resolution into 2.35:1 aspect ratio, adjust the width and
height as 1280 x 544.
