TVLogic F-10A User Manual

Field Production Monitor
37
F-10A OUTPUT VIDEO FORMAT
Frame rate
SDI OUT HDMI OUT
Input Video Format
SDI-OUT PORT
SDI-IN/OUT
(CAM LUT OFF)
SDI-IN/OUT
(CAM LUT ON)
HDMI
SDI
720 x 480i 59.94 Passive Through Active Through 1920 x 1080 60p 1920 x 1080 60p
720 x 576i 50 Passive Through Active Through 1920 x 1080 50p 1920 x 1080 50p
1280 x 720p 60/59.94/50 Passive Through Active Through Active Through Active Through
1280 x 720p 30/29.97 Passive Through Active Through Active Through Active Through
1280 x 720p 25/24/23.98 Passive Through Active Through 1920 x 1080 50p 1920 x 1080 50p
1920 x 1080i 30/29.97/25/24/23.98 Passive Through Active Through Active Through Active Through
1920 x 1080p 30sF/29.97sF Passive Through Active Through Active Through 1920 x 1080 60p
1920 x 1080p 25sF/24sF/23.98sF Passive Through Active Through Active Through 1920 x 1080 50p
1920 x 1080p 60/59.94/50 Passive Through Active Through Active Through Active Through
1920 x 1080p 30/29.97/25/24/23.98 Passive Through Active Through Active Through Active Through
2048 x 1080p 60/59.94/50 Passive Through Active Through Active Through Active Through
2048 x 1080p 30/29.97/25/24/23.98 Passive Through Active Through Active Through Active Through
2048 x 1080p 30sF/29.97sF/25sF/24sF/23.98sF Passive Through Active Through Active Through Active Through
HDMI
720 x 480i 59.94 Passive Through 1920 x 1080 60p 1920 x 1080 60p Active Through
720 x 576i 50 Passive Through 1920 x 1080 50p 1920 x 1080 50p Active Through
720 x 480p 60 Passive Through 1920 x 1080 60p 1920 x 1080 60p Active Through
720 x 576p 50 Passive Through 1920 x 1080 50p 1920 x 1080 50p Active Through
1280 x 720p 60/59.94/50 Passive Through Active Through Active Through Active Through
1920 x 1080p 60/59.94/50/30/29.97/25/24 Passive Through Active Through Active Through Active Through
1920 x 1080i 60/59.94/50 Passive Through Active Through Active Through Active Through
3840 x 2160p 60/59.94/30/29.97 Passive Through 1920 x 1080 60p 1920 x 1080 60p 1920 x 1080 60p
3840 x 2160p 50/25/24/23.98 Passive Through 1920 x 1080 50p 1920 x 1080 50p 1920 x 1080 50p
4096 x 2160p 50/25/24/23.98 Passive Through 1920 x 1080 50p 1920 x 1080 50p 1920 x 1080 50p
4096 x 2160p 60/59.94/30 Passive Through 1920 x 1080 60p 1920 x 1080 60p 1920 x 1080 60p
11 PRODUCT SPECIFICATIONS
F-10A
LCD
Size 10”
Resolution 1920×1080 (16:9)
Pixel Pitch 0.11475(H) X 0.11475(W) mm
Color Depth 16.7M
Viewing Angle (Typ.) 160º(H)/160º(V)
Luminance of white
300 cd/ m
2
(Max.)
Contrast Ratio 1000 : 1
Display Area 220.3(H)x123.9(V) mm
Input
1 X HDMI HDMI 2.0 Input
2 X BNC 3G-SDI * I/O integrated Chip
Output
1 X HDMI HDMI 1.4 Output 1Ch
1 X BNC 3G/HD/SD SDI Output 1Ch
Input Signal
3G-SDI 2.970Gbps
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
HDMI 480i / 480p / 576i / 576p / 720p / 1080i / 1080p
SDI Input Signal
Formats
SMPTE-425M-A/B
1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i(60/59.94/50)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
Audio In SDI Embedded Audio (Group, Ch Selectable)
Audio Out External Output Port (3.5m Phone Jack)
Power DC 6V / 2.5A, 34V 0.5A
Power Consumption (Approx.) 14W
Tally Signal In/Out Level DC5V ±2V
Operating Temperature
0℃ to 40℃ (32
℉
to 104
℉
)
Storage Temperature
-20℃ to 60℃ (-4
℉
to 140
℉
)
Main Body Dimensions (mm/inch) 258 x 154 x 29.8(mm) / 10.15 x 6.06 x 1.17(inch)
Box Dimensions (mm/inch) 290 X 158 X 83 (11.42 X 6.22X 3.27)
Weight 1.3kg / 2.86lbs
Basic Accessories BNC Connector, Camera Mount, D-Tap cable
Optional Accessories
Ball Head, Camera Mount, Battery Bracket, V-mount, G-Mount,
HDMI Bracket, Carrying Case, Acrylic Filter
*
The specication above may be changed without notice.
*
When using a DC Adapter other than the one supplied by the manufacturer, please be advised that the
adapter with DC 12V/3A ~ 6A can be compatible with the monitor.
