TVLogic F-10A - Firmware Upgrade Procedure

Field Production Monitor
33
07 OTHER FUNCTIONS
[10] FIRMWARE UPGRADE
• The USB(Thumb drive) which contains the F/W le is needed for Firmware Upgrade.
• Select the SW UPGRADE in the SYSTEM menu.
1. Connect the USB to the USB Slot on the front of the monitor.
2. Select what to update among CPU / FPGA / ALL in [S/W UPGRADE].
3. When the USB connection is completed, the S/W upgrade starts and the progress displays on the
bottom left side of the screen.
4. If the USB doesn’t connect properly or there is no  le in the speci ed location, the error message will
be displayed on the bottom left side of the screen and the upgrade won’t start.
5. In that case, check the USB or the le location and try again.
• After USB connection, turn o and then on the monitor.
