Field Production Monitor
32
[9] INTERNAL PATTERN
07 OTHER FUNCTIONS
<Color Bar + Pluge Pattern> <Gray Pattern>
• Displays internally generated test patterns.
- The pattern consists of ColorBar and Pluge+ Grayscale Patterns. Full screen colors of various gray levels
(0~100%) are also embedded.
