TVLogic F-10A User Manual

Field Production Monitor
31
07 OTHER FUNCTIONS
[8] HDMI To SDI SDI To HDMI CONVERSION-OUT / SDI To HDMI CONVERSION-OUT
●
3G/HD/SD SDI signals from‘SDI input’ terminal
can be output through‘HDMI out’terminal.
• Video source from ‘HDMI input’ terminal can be
output through ‘SDI throughout’ terminal.
Output
Format
Input
Format
1080p50 1080p60
480i(NTSC)
●
576i(PAL)
●
480P
●
576P
●
720P50
●
720P59.94
●
720P60
●
1080i50
●
1080i59.94
●
1080i60
●
1080p24
●
1080p25
●
1080p30
●
1080psF24
●
1080p50
●
1080p59.94
●
1080p60
●

※ Note: HDSLR camera manufacturers usually specify the resolution and frame rate for the recording. The
signal format that is output through HDMI terminal of cameras may dier from makers to makers. The
signal format for HDMI output and playback function of Canon HDSLRs is 59.94i. And even though 60i or
60p is specied in the specication of the cameras, the actual recording or HDMI output format would be
59.94i or 59.94p.
Output
Format
Input
Format
1080p50 1080p60
480i(NTSC)
●
576i(PAL)
●
720P50
●
720P59.94
●
720P60
●
1080i50
●
1080i59.94
●
1080i60
●
1080p24
●
1080p25
●
1080p30
●
1080psF24
●
1080p50
●
1080p59.94
●
1080p60
●
     

HDMI TO SDI CONVERSION-OUT SDI TO HDMI CONVERSION-OUT
