TVLogic F-10A User Manual

Field Production Monitor
36
* Active Through : same as input format
F-10A OUTPUT VIDEO FORMAT
Frame rate
SDI OUT HDMI OUT
Input Video Format
SDI-OUT PORT
SDI-IN/OUT
(CAM LUT OFF)
SDI-IN/OUT
(CAM LUT ON)
HDMI
SDI
720 x 480i 59.94 Passive Through Active Through 1920 x 1080 60p 1920 x 1080 60p
720 x 576i 50 Passive Through Active Through 1920 x 1080 50p 1920 x 1080 50p
1280 x 720p 60/59.94/50 Passive Through Active Through Active Through Active Through
1280 x 720p 30/29.97 Passive Through Active Through Active Through Active Through
1280 x 720p 25/24/23.98 Passive Through Active Through 1920 x 1080 50p 1920 x 1080 50p
1920 x 1080i 30/29.97/25/24/23.98 Passive Through Active Through Active Through Active Through
1920 x 1080p 30sF/29.97sF Passive Through Active Through Active Through 1920 x 1080 60p
1920 x 1080p 25sF/24sF/23.98sF Passive Through Active Through Active Through 1920 x 1080 50p
1920 x 1080p 60/59.94/50 Passive Through Active Through Active Through Active Through
1920 x 1080p 30/29.97/25/24/23.98 Passive Through Active Through Active Through Active Through
2048 x 1080p 60/59.94/50 Passive Through Active Through Active Through Active Through
2048 x 1080p 30/29.97/25/24/23.98 Passive Through Active Through Active Through Active Through
2048 x 1080p 30sF/29.97sF/25sF/24sF/23.98sF Passive Through Active Through Active Through Active Through
HDMI
720 x 480i 59.94 Passive Through 1920 x 1080 60p 1920 x 1080 60p Active Through
720 x 576i 50 Passive Through 1920 x 1080 50p 1920 x 1080 50p Active Through
720 x 480p 60 Passive Through 1920 x 1080 60p 1920 x 1080 60p Active Through
720 x 576p 50 Passive Through 1920 x 1080 50p 1920 x 1080 50p Active Through
1280 x 720p 60/59.94/50 Passive Through Active Through Active Through Active Through
1920 x 1080p 60/59.94/50/30/29.97/25/24 Passive Through Active Through Active Through Active Through
1920 x 1080i 60/59.94/50 Passive Through Active Through Active Through Active Through
3840 x 2160p 60/59.94/30/29.97 Passive Through 1920 x 1080 60p 1920 x 1080 60p 1920 x 1080 60p
3840 x 2160p 50/25/24/23.98 Passive Through 1920 x 1080 50p 1920 x 1080 50p 1920 x 1080 50p
4096 x 2160p 50/25/24/23.98 Passive Through 1920 x 1080 50p 1920 x 1080 50p 1920 x 1080 50p
4096 x 2160p 60/59.94/30 Passive Through 1920 x 1080 60p 1920 x 1080 60p 1920 x 1080 60p
10 OUTPUT VIDEO FORMATS
