Field Production Monitor
7
03 CONTROLS & FUNCTIONS
F-10A ALL PART
PHONEJACK
HDMI OUT
HDMI IN
KNOB
MENU<EXIT>
SOURCE
USB
DC POWER
ETHERNET
GPI
SDI IN/OUT
(SELECT)
SDI OUT
REAR TALLY
SDI IN
POWER BUTTON
FUNCTION F1~F6
