TVLogic F-10A - Video Support Resolution

Field Production Monitor
35
09 VIDEO SUPPORT RESOLUTION
INPUT SIGNAL INTERFACES SIGNAL FORMAT (SD SDI)
SD SDI
single link
720x487 (59.94i)
720x576 (50i)
YCbCr 4:2:2 10bit
INPUT SIGNAL INTERFACES SIGNAL FORMAT (HD SDI)
HD SDI
single link
1280x720 (50/59.94/60P)
1920x1080 (23.98/24/25/29.97/30p) (50/59.94/60I)
(24/25/29.97/30psf)
YCbCr 4:2:2 10bit
INPUT SIGNAL INTERFACES SIGNAL FORMAT (3G SDI)
3G-SDI (A/B)
single link
1920x1080 (60p/59.94p/50p) YCbCr 4:2:2 10bit
1920x1080 (30/29.97/25/24/23.98/
30sF/29.97sF/25sF/24sF/23.98sF)
1920x1080i (60/59.94/50)
YCbCr 4:2:2 12bit
RGB 4:4:4 10bit / 12bit
YCbCr 4:4:4 10bit / 12bit
1280x720 (50/59.94/60P)
RGB 4:4:4 10bit
YCbCr 4:4:4 10bit
2048x1080 (60/59.94/50/30/29.97/25/24/23.98
30sF/29.97sF/25sF/24sF/23.98sF)
RGB 4:4:4 8bit / 10bit / 12bit
YCbCr 4:4:4 8bit / 10bit / 12bit
YCbCr 4:2:2 8bit / 10bit / 12bit
INPUT SIGNAL INTERFACES SIGNAL FORMAT (HDMI / DP)
HDMI
Single link
1080p (60/59.94/50/30/29.97/25/24/23.98)
1080i (60/59.94/50)
720p (50/59.94/60p)
480i(60) / 576i(50)
480p(60) / 576p(50)
RGB 4:4:4 8bit / 10bit / 12bit
YCbCr 4:2:2 8bit / 10bit / 12bit
YCbCr 4:2:2 8bit / 10bit / 12bit
1280x720(50/59.94/60p)
1920x1080(50/59.94/60p)
1920x1080(23.98/24/25/29.97/30p,60i/59.94i/50i )
* HDMI
RGB 4:4:4 8bit
YCbCr 4:4:4 8bit
YCbCr 4:2:2 8bit
3840x2160 (23.98/24/25/29.97/30p/50/59.94/60p)
RGB 4:4:4 8, 10, 12bit
YCbCr 4:4:4 8, 10, 12bit
YCbCr 4:2:2 8, 10, 12bit
YCbCr 4:2:0 8, 10, 12bit
4096x2160 (23.98/24/25/29.97/30p/50/59.94/60p)
RGB 4:4:4 8, 10, 12bit
YCbCr 4:4:4 8, 10, 12bit
YCbCr 4:2:2 8, 10, 12bit
YCbCr 4:2:0 8, 10, 12bit
