Chapter 3
Onboard Resource Settings
chapter 3
Onboard Resource Settings
Quick References for Jumpers
The tables on the following pages will help you set the jumpers for CPU speed,
wake on events, and external connector pin assignments among other things.
The miniature motherboard maps will help you locate the jumpers on your board.
A full-page map of the motherboard can be found on the facing page.
