Chapter 4
BIOS Configuration
Standard Setup
Select the AMIBIOS Setup options below by choosing Standard Setup from
the AMIBIOS Setup main menu. The Standard Setup menu screen is shown
below.
Primary Master, Primary Slave, Secondary Master, Secondary Slave
Select these options to configure the various drives. A screen with a list of
drive parameters appears.
Type: To have the BIOS autodetect the IDE drive, select Auto. Otherwise, you
may choose one of the 46 drive types offered, or enter the parameters yourself
(see Entering Drive Parameters on the next page). Consult the table at the top
of the next page to see how to configure various drive types yourself. (If Type
is set to Auto, then LBA/Large
Mode, Block Mode, and PIO Mode will be autodetected.)
Standard Setup
Pri Master Pri Slave Sec Master Sec Slave
Date/Time Floppy A Floppy B
Primary Master Hard Disk
Type : User
LBA/Large Mode : On
Block Mode : On
32bit Mode : On
PIO Mode : 4
