23
J118: BMC COM Port Jumper (RX)
Signal Pin Pin Signal
BMC_COM2_RXD 1 2 RXD_2
SP_BMC_UART5_RXD 3
Pin1-2 closed: BMC COM PORT2 (Default)
Pin2-3 closed: BMC CONSOLE PORT5
J119: BMC COM Port Jumper (TX)
Signal Pin Pin Signal
BMC_COM2_TXD 1 2 TXD_2
SP_BMC_UART5_TXD 3
Pin1-2 closed: BMC COM PORT2 (Default)
Pin2-3 closed: BMC CONSOLE PORT5
J1_PCH: BIOS Recovery Jumper
Signal Pin Pin Signal
TP_BIOS_RCVR_BOOT 1 2 FM_PCH_BIOS_RCVR_MODE
PU_BIOS_RCVR_BOOT 3
Pin1-2 closed: Normal Mode (Default)
Pin2-3 closed: Recovery BIOS
J2_PCH: Password Clear Jumper
Signal Pin Pin Signal
NC 1 2
F
M_PASSWORD_CLEAR_N
PD_PASSWORD_CLEAR 3
Pin1-2 closed: Normal Mode (Default)
Pin2-3 closed: PASSWORD CLEAR
J3_PCH: ME Recovery Jumper
Signal Pin Pin Signal
PU_ME_RCVR_BOOT 1 2 FM_ME_RCVR_N
PD_ME_RCVR_N 3
Pin1-2 closed: Normal Mode (Default)
Pin2-3 closed: RECOVER ME
J4_PCH: MFG Mode Jumper
