J75：SAS2008 Enable
Pin_3 Pin_1
Pin_3 Pin_1
⑴NC/⑵RESET#/⑶GND
(1-2: Enable (default) 2-3: Disable)
J78：VGA Enable
Pin_3 Pin_1
Pin_3 Pin_1
⑴NC/⑵RESET#/⑶GND
(1-2: Enable (default) 2-3: Disable)
