3.7.2.1 - IDE Configuration Sub-Menu
Type
Select the type of device connected to the system
[Not Installed]/[ Auto]/ [CD/DVD]/ [ARMD]
LBA/Large Mode
Auto: Enables LBA Mode if the device supports it and the device is not already
formatted with LBA Mode disabled.
Disabled: Disables LBA Mode
[Disabled]/[ Auto]
Block(Multi-Sector Transfer
Disabled: The data transfer from and to the device occurs one sector at a time.
Auto: The data transfer from and to the device occurs multiple sectors at a time if
the device supports it.
[Disabled]/[ Auto]
PIO Mode
Select Auto to enhance hard disk performance by optimizing the hard disk timing.
[Auto]/ 0~4(at 1 interval)
DMA Mode
Auto: Auto detected
[Auto]
S. M. A. R. T
S. M. A. R. T stands for Self-Monitoring，Analysis and Reporting Technology.
[Auto]/[ Disabled]/[ Enabled]
32 Bit Data Transfer
Enable/Disable 32-bit Data transfer
[Disabled]/[Enable]
