3.7.3 - Super I/O Configuration Sub- Menu
Serial Port1 Address
Allows BIOS to configure Serial Port1 Base Address.
[Disabled] / [3F8/IRQ4] / [2E8/IRQ3]
Serial Port2 Address
Allows BIOS to configure Serial Port2 Base Address.
[Disabled] / [2F8/IRQ3] / [2E8/IRQ3]
Serial Port2 Mode
Allows BIOS to select mode for Serial Port2.
[Normal] / [IrDA] / [Ask IR]
Parallel Port Address
Allows BIOS to select Parallel Port Base Address.
[Disabled] / [378] / [278] / [3BC]
Parallel Port IRQ
Allows BIOS to select Parallel Port IRQ
[IRQ7] / [IRQ5]
