CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 16 May 2006 101
On-Line Capacity Available battery reserve from installed capacity value directly
connected to the bus. It is always the same value configured for
installed capacity except for when the smart lithium batteries are
utilized.
Current Current flowing into or out of the batteries.
Number Of Strings The total number of battery strings installed in the system.
Highest Temp Highest battery temperature being measured by the thermal probes.
Temp Probes Number of installed thermal probes.
Mid-Cell Volts Number of installed Mid-cell voltage measurement modules.
Battery Test Result Shows whether the most recent battery test was completed, and the
reserve time.
Next Test The date of the next automatic battery discharge test. The automatic
discharge test feature must be enabled for this to work.
Live Reserve Time Present value of battery reserve time calculated by the controller
Shunt Currents:
A maximum of six measured currents from each Distribution Control
and Monitoring module present in the system is displayed.
Disconnect States: The status of the LVBD (Low Voltage Battery Disconnect) and
LVLD1-3 (Low Voltage Load) disconnects are displayed. “None” is displayed if
there are no contactors in the system.
Alarm Thresholds: Present alarm threshold settings in xx.xV format of the following system
alarms:
Float Voltage
Alarms
Very High Major, Very High Minor, BD Major and Very Low
Major
Boost Voltage
Alarms
Very High Major and High Minor
High Batt Temp Highest temperature being measured by the thermal probes
Reserve Low Low battery reserve time
High Ambient Temp High ambient temperature
Low Ambient Temp Low ambient temperature
Ringer Thresholds: Present status of up to two ringer chassis:
State Ringer chassis present or not
VA Output VA of ringer
Primary Ringer module present in primary position
Secondary Ringer module present in secondary/redundant position
