CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 16 May 2006 102
Enable-Disable Info: Displays the enable/disable status of the following features:
Temp Comp Temperature compensation
Low Temp Comp Low temperature compensation
Recharge Ilim Recharge current limit
Auto Boost Automatic boost charge
Auto Batt Test Automatic battery test
Rect Redund Rectifier redundancy
Mid-Cell V Mon Mid-cell voltage monitoring
Imminent Shutdn Imminent system shutdown alarm (LVBD)
Local Write Whether or not the system can be configured through the local
port.
Modem Write Whether or not the system can be configured through the
modem port.
System Info: Various high level system statuses.
Controller Info Provides the versions of software for the overall controller
(QS840A_MC1), boot block of the controller, display, and the
defaults.
Date System controller present date using configured format.
Time System controller present time using configured format.
Ambient Temperature System controller present temperature using configured format.
Control/Operations
The following are the system control and operation functions that can be performed from the
front panel. These operations are generally used in post installation and maintenance modes.
Start Lamp Test Temporarily illuminates all status indicators of attached rectifiers,
distribution monitoring and control modules and the system controller.
Restart Rectifiers Restarts all system serial controlled rectifiers. Does not affect rectifiers,
and other system devices that are already functioning.
Clear Events Used to clear momentary events or alarms. It clears the following
system alarms: Check Battery, Reserve Time Low, Battery Voltage
Imbalance
Uninstall
Equipment
Clears alarms related to the removal of a system component such as a
rectifier, thermal probe, or voltage monitoring module.
Alarm Test Initiates the asserting the Form-C alarms.
Start Battery Test Initiates the manual battery test feature. A stop battery test operation is
displayed to interrupt the testing and return the unit to normal operation.
The manual battery test utilizes the configured test duration and a
system bus voltage threshold to represent the end of reserve.
Start Boost Initiates the manual battery Boost feature. A stop battery Boost
