CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 16 May 2006 17
Specifications
Table 2-A: CPS6000 System Specifications
Shelf Single 19-inch or 23-inch shelf
Power Slots per Shelf 4 (19-inch shelf), 5 (23-inch shelf)
Power Units
Installed Position
5
Unit
Max. per
Shelf
Power Slots
Each
Installed from the Right
Bulk Output Module
Distribution Module
Ringer Chassis
Installed from the Left
Rectifiers
Bulk Output Module
Single-Slot Distribution Module
Double-Slot Distribution Module
Ringer Chassis
Rectifiers (19-inch shelf)
(23-inch shelf)
1
1
1
2
4
5
0
1
2
1
1
1
Rectifier Input Distribution Dual ac input (19 and 23-inch shelves)
Individual ac input (19 and 23-inch shelves)
Single ac input (19 and 23-inch shelves)
System Architecture Primary output: 1 primary output power bus per shelf
Primary Power Bus Current
with Bulk Output Module
19-inch shelf: 227A
23-inch shelf: 283A
Output Distribution Primary Bus
Bulk Output Module
Single-Slot and Double-Slot
Distribution Modules
Battery connections: double-hole lugs to terminate battery
strings.
-48 Vdc bulk power outputs to loads or distribution
• Bullet-style circuit breakers
• GMT-style fuses
See Note 2.
Maximum Discharge Current Based on rectifier capacity. See Note 2
Maximum Recharge Current Installed shelf –48V rectifier capacity minus plant –48V load
Operating Ambient Temperature -40 to 75 °C (-40 to 167 °F), see Note 3
Altitude -200 to 13,000 feet (-61 to 3962 meters). See Note 4
Humidity 10% to 95% non-condensing
Audible Noise < 60 dBA
Radiated and Conducted Emissions FCC Part 15, Class B
EN55022 (CISPR22), Class B
Harmonics EN61000-3-2 (IEC61000-3-2)
Voltage Fluctuations EN61000-3-3 (IEC61000-3-3)
Electromagnetic Immunity Meets Telcordia GR-1089-CORE
Electrostatic Discharge EN61000-4-2 Level 3
RF Immunity IEC61000-4-3 Level 3, 10 V/m
EFT IEC61000-4-4 Level 3, No Error; Level 4, No Damage
Surge IEC 61000-4-5 Level 3, No Error; Level 4, No Damage
Conducted Immunity IEC 61000-4-6 Level 3, 10V
Voltage Dips, Interruptions, and Variations IEC 61000-4-11
Earthquake Rating Zone 4, upper floors
Underwriters Laboratories (UL) Listed per Subject Letter 1801:
Power Distribution Center for Communications Equipment, and
cUL Certified (CSA 22.2 950): Safety of Information
Technology Equipment
Safety Agency Approval
VDE licensed to VDE0805/EN60950
