CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 16 May 2006 24
Thermal Limiting Output VA may be reduced by reducing Vac when
operating simultaneously above 50°C and less than
-50Vdc input.
Vac is reduced only sufficiently to prevent damage to
the ringer.
Load Power Factor Operating: 0.5 Leading to 0.9 Lagging
No Damage: 0 Leading to 0.7 Lagging
Operating Temperature -40 to +75 °C See Output VA Thermal Limiting.
Heat Dissipation 50 W (170 BTU / hr)
Under Voltage Shutdown 50% of Output Vac Set Point
While shutdown due to external fault, restart will be
performed at approximately 2 minute intervals.
Table 2-L: QS840A and QS841A Control Unit Specifications
Operating Input Voltage Range 38 to 60 Vdc
Input Power 6.0 watts maximum
Plant Parameter Setting Through front panel LCD display and menu keys or with IBM
compatible PC with RS-232 port. 841 also has 10/100 Baset-T
network ability
Alarm Contact Ratings 60 Vdc, 0.5A, Form-C
Operating Temperature -40 to +75 °C
Table 2-M: QS845A Supplementary Board Specifications
Operating Input Voltage Range Input power through QS840A or QS841A
Plant Parameter Setting None, communicates with shelf components QS840A/QS841A
Alarm Contact Ratings None
Operating Temperature -40 to +75 °C
