CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 16 May 2006 28
Distribution Module Lugs
The 3.4-inch wide Distribution Modules require M5 double hole lugs on 5/8-inch centers for
battery breaker and CO ground connections. Straight lugs may be used for most applications.
Office Alarm Cable
WARNING
Disconnect alarm cable before cutting it to length. Cutting the alarm cable while it is
plugged into the controller will damage the controller.
A cable assembly is available that mates to the host-interface connector on the controller
allowing access to alarms. This cable is terminated on one end with a connector that mates to
the Distribution Module host-interface connector, and un-terminated on the other end.
Distribution Module Circuit Breakers
The following bullet-style circuit breakers, which have been accepted for use in dc load and
battery applications, are available for the current Distribution Module. These breakers only
alarm for a trip condition. For a single slot distribution module, a max of two 60A load
breakers can be used. If only a single breaker is used in the topmost position, a 70A breaker
may be used
Size (Amps) Comcode Size (Amps) Comcode
3 407998137 25 407998194
5 407998145 30 407998202
10 407998152 45 407998210
15 407998160 50 407998228
16 407998178 60 407998236
20 407998186 70 407998244
Some versions of the distribution module accept breakers that alarm for trip or open
condition. The comcodes for such breakers are provided below. These breakers can ONLY be
used with specific distribution modules
Size (Amps) Comcode Size (Amps) Comcode
3 CC408606834 25 CC408606883
5 CC408606842 30 CC408606891
10 CC408606850 40 CC408606900
15 CC408606867 45 CC408606917
20 CC408606875 50 CC408606925
Pluggable Strap
Size(Amps) Comcode
100A Pluggable Strap CC109106548
Distribution Module GMT Fuses
The following GMT fuses have been accepted for use in dc load applications, are available
for the current Distribution Module.
