CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 16 May 2006 33
Table 3-C: Rectifier AC Input Current Table
Tyco
Rectifier (A)
Model
Number of
Rectifier
Nominal
Input
Voltage
Number of
Rectifiers
per AC feed
Nominal AC
Current (A)
Minimum Circuit
Breaker value
recommended
(A)*
75°C Minimum
Recommended
Wire Gauge
(AWG)*
120 1 7.8 15 14
120 2 15.6 20 12
120 3 23.4 30 10
120 4 31.2 40 8
120 5 39.1 50 8
208 1 4.4 15 14
208 2 8.8 15 14
208 3 13.2 20 12
208 4 17.6 25 10
15A QS861A
208 5 22.0 30 10
208 1 6 15 14
208 2 12 15 14
208 3 18 25 10
208 4 24 30 10
20A QS852A
208 5 30 40 8
208 1 7.4 15 14
208 2 14.8 20 12
208 3 22.2 30 10
208 4 29.6 40 8
25A QS853A
208 5 37.0 50 8
120 1 13.0 20 12
120 2 26.0 35 8
120 3 39.1 50 8
208 1 8.8 15 14
208 2 17.6 25 10
208 3 26.4 35 8
25/30A QS862A
208 4 35.3 45 8
208 1 11.8 15 14
208 2 23.5 30 10
40A QS864A
208 3 35.3 45 8
208 1 14.5 20 12
208 2 29.1 40 8
50A QS865A
208 3 43.6 60 6
*Conduit and further temperature deratings may be required in some installations .Cross-check table with
local code and regulation requirements
Thermal Compensation
Thermal Compensation: For thermal compensation, the QS873A Voltage/Thermal probe
(VT-Probe) and its associated cables must be ordered. Refer to Section 5 for details on their
interconnection, and Section 9 for more information on VT-Probes. The probe is provided
with a weatherproof case.
Thermal Compensation/Voltage Monitoring: When voltage monitoring for battery string
voltage imbalance detection is to be implemented in addition to thermal compensation, the
VT-probe and its associated cables must be ordered. Refer to Section 5 for details on their
interconnection, and Section 9 for more information on VT-Probes and voltage monitoring.
