CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 16 May 2006 56
Step Action
1. Insert the H569-470A ac cord into the ac receptacles on the CPS shelf. Refer
Figure 5-12a, b, c or d for the appropriate shelf
2. Terminate the supply end of the cable with an appropriate plug (plug not
provided).
Figure 5-12a: Dual AC Input Connections
