CPS6000 –48V Indoor/Outdoor Power Shelf
Issue 16 May 2006 85
Serial Port
The appropriate IP address, subnet mask, hostname, and default gateway IP
address must be configured on the QS841A through serial port J3.
To login to the QS841A, follow these steps:
a. Start-up the PC terminal program (Windows Terminal,
ProComm, etc.) using the following communication
parameters:
Baud : 9600
Data : 8
Parity : none
Stop : 1
Handshaking: none
Flow Control: none
b. Connect the PC to the QS841A local port (RS-232) connector
J3
c. Wait for any diagnostic messages to pass.
d. Wait for the “ENTER PASSWORD:” command line prompt.
e. Type the Network Administrator password (default:
administrator).
f.
Wait for the “$” prompt.
8A Configuring Static Network Parameters
After a valid password entry, a login header with the following format similar
to that below will be displayed:
Board Code QS841A
Serial Number 05DJ09112345
Boot Block version 1.0
Application Code version 1.0
Default Web Pages version 1.0
Custom Web Pages not found
Ethernet Address 00-60-1D-00-5C-07
IP Address not configured
Subnet Mask not configured
Default Gateway not configured
Host Name not configured
For assistance type help
$
Typing HELP at the “$” will show all available network administration
commands and command line formats.
*note: 1) commands are not case sensitive
2) for the commands that follow, ddd is a number from 0 – 255
• To set the IP Address, type:
