TYM T394C - Greasing; Greasing Points

5 - 13
MAINTENANCE AND SERVICE
43
5
■ STANDARD
GREASING POINTS
For general greasing points, refer
to the fuel, oil and fluid specification
chart. (See page 5-22.)
However, add grease before work
if the tractor is to be used in a wet
field.
GREASING BRAKE ARM
Remove the rubber caps on the
floor and dash panel to access to
the grease nipple.
Add grease with the supplied grease
gun.
►
►
9. GREASING
Tightening torque
1,600~1,800kg cm
1,175
1,387
*
*
Tightening torque
2,000~2,300kg cm
Tightening torque
1,600~1,800kg cm
1,040
1,056
1,140
1,156
1,256
T4NO510A
Tightening torque
1,600~1,800kg cm
* 1,175
Tightening torque
2,000~2,300kg cm
*1,040
1,387
Tightening torque
1,600~1,800kg cm
1,056
1,140
1,156
1,256
