CIRCULATION DIFFUSER
With the circulation vent set in any
position outside air will still be pulled
into the cab.
►
HEATING SYSTEM
The heater is switched on and ad-
justed by rotating the control knob
at the roof console, then switching
on the blower and setting the selec-
tor at the preferred speed.
Warm the cab up quickly, the knob
should be rotated fully clockwise
and the blower set to speed 3.
The screen is demisted or defrosted
by air directed through a slot vent.
For defrost or fast demist, all other
vents should be closed off.
►
NOTE
For ideal system operation, the
engine must run at 1,000 rpm.
②
Speed heating fan
③
Electric resistances
④
Air lter
⑤
Recirculation inlets
⑥
Pivotal air diffuser
T72O615A
Ventilation is provided by a
single blower unit serving both
the heating system and the air
conditioning system.
After reaching the desired
temperature adjust the system
to suit your needs.
IMPORTANT
T4NO606A
Circulation Diffuser
