TYM T394C - Operation the Controls

DESCRIPTION OF TRACTOR CONTROLS
2 - 18
5. OPERATION THE CONTROLS
Cluster
T4NO227A
Key switch
PTO ON/OFF switch
Hazard switch
Shuttle shift lever
Turn signal switch
Regen switch
Info switch
Horn switch
Light switch
PTO Mode switch
Clutch Pedal
Throttle Lever
Tilt lever
Brake Pedal
Accel Padal
Parking Lever
Joy Stick
Lever
