CIRCULATION DIFFUSER
With the circulation vent set in any
position outside Air will still be pulled
into the cab.
►
①
Alternator
②
Compressor
③
Speed fan
④
Electric resistance
⑤
Evaporator
⑥
Condenser
⑨
Air lter
⑩
Recirculation inlets
⑪
Pivotal air diffusers
T72O616A
CAB AIR INTAKE FILTER
The "paper" lter is not suitable for
the treatment of pesticides and so
must be replaced by an "active car-
bon" lter available optionally. Once
the pesticide treatment is nished, it
is necessary to once again replace
the "Active carbon" lter with the pa-
per lter, since this is the only type
suited for filtering foreign particles
from the air.
►
T72O618A
Air Intake Filter
