▶GENERAL CONSTRUCTION
The transmission case, Clutch,
Clutch housing, Engine and Front
Axle Support are bolted together to
form a rigid unit.
▶FRONT AXLE & WHEELS
The 4WD front axle is a center-piv-
ot, reverse Eliot type. The front
wheel drive mechanism is incorpo-
rated as a part of the axle.
The front wheel drive power is taken
off the rear transmission and trans-
mitted to the differential in the front
axle where the power is divided into
right and left and to the respective
nal cases.
In the final cases, the transmitted
revolution is reduced by the level
gears to drive the front wheel. The
4WD mechanism with level gears
provides wider steering and greater
durability.
▶ENGINE
The tractors are fitted with vertical,
Water-cooled 4-cycle and spherical
chamber type YANMAR
ENGINES (3TNV88C-DKTF)
▶ CLUTCH AND TRANSMISSION
A single plate dry clutch (8.86″ di-
ameter) is used on these tractors.
Tractor with IPTO (Independent
Power Take Off) are fitted with hy-
draulic Clutch Ass`y.
The transmission Gear box has
Twelve forward speeds & Twelve re-
verse speeds with high-low selector
lever, Presently, TYM Tractors are
tted with partial synchro-mesh type
gears.
▶REAR AXLE & WHEELS
This is mounted on ball bearings
and is enclosed in removable hous-
ing which are bolted to the transmis-
DESCRIPTION
sion case. The rim & Disc tted with
Rear tires are bolted to the outer
ange of Rear Axle.
▶
HYDRAULIC SYSTEM & LINK-
AGES
TYM Tractors are tted with Live (i.e.
system is in operation) independent,
very touch of hydraulic System.
Three point Linkages can be used
for category 1 type of implements.
▶
STEERING
It consists of Hydrostatic Power
steering system, which has a hy-
draulic cylinder and tandem type hy-
draulic pump.
▶
ELECTRICAL SYSTEM
A 12 Volt Lead Acid Propylene Bat-
tery is used to activate the Engine
