▶GENERAL CONSTRUCTION
The transmission case, Engine and
Front Axle Support are bolted to-
gether to form a rigid unit.
▶FRONT AXLE & WHEELS
The 4WD front axle is a center-piv-
ot, reverse Eliot type. The front
wheel drive mechanism is incorpo-
rated as a part of the axle.
The front wheel drive power is taken
off the rear transmission and trans-
mitted to the differential in the front
axle where the power is divided into
right and left and to the respective
nal cases.
In the final cases, the transmitted
revolution is reduced by the level
gears to drive the front wheel. The
4WD mechanism with level gears
provides wider steering and greater
durability.
▶E
NGINE
The tractors are fitted with vertical,
Water-cooled 4-cycle and spherical
chamber type YANMAR
ENGINES(3TNV88C-DKTF)
▶ TRANSMISSION WITH HST (HY-
DROST
ATIC TRANSMISSION)
The Tractor is fitted HST with 3
Range and can be selected Speed
range by HIGH-LOW selector lever.
The Tractor has Two pedals for for-
ward/reverse control . Tractor with
Independent Power Take Off
is tted with electro-hydraulic Clutch
Assy. The Rear PTO can be operat-
ed both or separately by a lever.
TYM tractors are provided with in-
dependent disc brakes operated by
two road travel. A foot brake lever is
tted for parking.
DESCRIPTION
▶REAR AXLE & WHEELS
This is mounted on ball bearings
and is enclosed in removable hous-
ing which are bolted to the transmis-
sion case. The rim & Disc tted with
Rear tires are bolted to the outer
ange of Rear Axle.
▶HYDRAULIC SYSTEM & LINK-
AGES
TYM Tractors are tted with Live (i.e.
system is in operation) independent,
very touch of hydraulic System.
Three point Linkages can be used
for category 1 type of implements.
▶STEERING
It consists of Hydrostatic Power
steering system, which has a hy-
draulic cylinder and tandem type hy-
draulic pump.
