TYPHOON Q500 4K - ST10+ Transmitter Display; ST10+ Display Functions

11
ST10+ Display
1 Model Name
2 Status Informaon
3 Direcon to Home Point
4 Clock/Current Time
5 Watch Me/Follow Me Buon
6 GPS Status and Number of Satellites for ST10+
7 ST10+ Baery Charge Level Status Icon
8 Aircra Baery Voltage
9 Altude of Aircra (Above Ground Level)
10 Ground Speed of Aircra
11 Distance of Aircra from Home Point
12 Model Select Menu Buon
13 In Flight Sengs
14 Flight Sengs Menu Buon
15 System Sengs Menu Buon
16 Latude/Longitude Posion of Aircra
17 Number of Satellites for Aircra
18 GPS Status for Aircra
19 Flight Mode of Aircra
The ST10+ is equipped with a touchscreen display that allows for changing various sengs and viewing real-me telemetry data and streaming video during
flight.
QUICK TIP: 1. Double tap on the screen to increase the size of the video viewing area to full-screen and double tap again to return to the standard size).
2. Single tap to hide the camera sengs, tap again to display camera sengs
WARNING: NEVER aempt to fly the TYPHOON via First-Person View (FPV). There’s a slight ‘lag’ in the CGO3 streaming video downlink to the ST10+,
and as a result the streaming video/FPV should only be used for aligning camera shots and not for flying! Aempng to fly via FPV can result in a crash that
will cause damage to the product, property and/or cause serious injury.
IMPORTANT NOTE: Streaming video from the CGO3 to the ST10+ and to a separate phone/tablet (or another Yuneec transmier/personal ground
staon) at the same me is NOT recommended as it will result in a very significant lag in the video downlink.
