TYPHOON Q500 4K - ST10+ and CGO3 Binding

ST10+ and CGO3 Binding
Step 1) Turn on the ST10+, and if required tap the screen (outside of the
pop up status window) to bypass the RC and WiFi connecon process.
Step 5) if required tap the
screen (outside of the pop
up status window) to
bypass the RC and WiFi
connecon process, then
tap the ‘Flight Sengs’
buon and press ‘OK’ to
bypass any pop up
warnings/alerts.
Step 6) Tap the ‘Bind’
buon and select the
‘CGO3_XXXXXX’ camera
listed in the column under
‘Camera’, then enter the
password ‘1234567890’
when prompted and tap
‘OK’ aer the connecon
has been established.
Step 7) Tap the ‘Back’ buon two (2) mes to return to the main screen and
the camera should automacally connect to the ST10+.
IMPORTANT NOTE: Streaming video from the CGO3 to the ST10+ and to
a separate phone/tablet (or another Yuneec transmier/personal ground
staon) at the same me is NOT recommended as it will result in a very
significant lag in the video downlink.
Step 2) Tap the ‘Model
Select’ buon, and if
required press ‘OK’ to
bypass any pop up
warnings/alerts.
Step 3) Select the exisng
model (for example: ‘the
TYPHOON’) you would like
to bind to (or create a ‘New
Model’), and if required
press ‘OK’ to bypass any
pop up warnings/alerts.
Step 4) Turn on the
TYPHOON and ensure that
the CGO3 is powered on.
28
Model: 4K Welcome,Pilot 10:48:28 pm
10
GPS
Ready
SAT
13
POS
00.0000E
00.0000N
MODE
Angle
ALT
21.4 
VOLTS
12.3 V
G-SPD
0.0 mph
DIS
22.5 
System Sengs Flight Sengs Model Select
HOME
Model: 4K Welcome,Pilot 10:48:28 pm
10
Model Select
New Model gh
Model: 4K Welcome,Pilot 10:48:28 pm
10
GPS
Ready
SAT
13
POS
00.0000E
00.0000N
MODE
Angle
ALT
21.4 
VOLTS
12.3 V
G-SPD
0.0 mph
DIS
22.5 
System Sengs Flight Sengs Model Select
HOME
Model: 4K Welcome,Pilot 10:48:28 pm
10
SR24_16042
SR24_16042
Not connected
Model Camera
