TYPHOON Q500 4K - Calibration Procedures; Compass Calibration

Compass Calibraon
Step 5) When the main LED status
indicator flashes red and green
slowly (2 mes per second) you
have entered compass calibraon
mode. Pick up the aircra and hold
it flat with the nose pointed to the
north. Aer 5 seconds the main
LED status indicator should flash
red and green rapidly (5 mes per
second).
Step 7) Rotate the aircra 45
degrees to the le. Then slowly
rotate the aircra 360 degrees
toward the north (as illustrated)
unl it's flat and upright in your
hands again.
Step 6) Slowly rotate the aircra
360 degrees toward the north (as
illustrated) unl it's flat and upright
in your hands again.
Step 8) Rotate the aircra 45
degrees to the le. Then slowly
rotate the aircra 360 degrees
toward the north (as illustrated)
unl it's flat and upright in your
hands again.
Step 1) Do not calibrate the compass
inside parking structures, near
buildings or surfaces with metal in
them (like roads parking lots with
rebar). Only calibrate the compass in
open areas/fields far away from
power lines and other metallic or
concrete surfaces/structures.
Step 2) Turn on the transmier and
allow it to boot up fully before
turning on the aircra. And when
the transmier and aircra are
powered on and linked proceed to
the next step.
25
Step 4) If successful, THPHOON
will beep, Return to the main
screen. 'Mag Cali' will be displayed
in MODE area.
CAMERA
MULTICOPTER
Video Sengs
Audio Switch
GPS
Calibraon
OFF
ON
Compass
Accelerometer
Step 3) Tap the Seng buon on
the ST10+ screen, then tap the
Calibraon buon. Choose Compass
opon and tap it.
Model:Q500 4K Welcome,Pilot 07:25
GPS
N/A
SAT
N/A
POS
N/A E
N/A N
MODE
Mag Cali
ALT
N/A 
VOLTS
N/A V
G-SPD
N/A mph
DIS
N/A 
System Sengs Flight Sengs Model Select
WB
ISO 32
1/250s
Auto
Auto
Lock
Sunny
Cloudy
Fluorescent
AWB
3840 x 2160 F30
