Chapter 1: Introduction
3
Features
The major features of the PowerDAQ AO boards are:
24-bit 66/100 MHz Motorola 56301 DSP (Digital Signal
Processor)
“Bus Master Ready” PCI Bus Host PC Interface (PCI 2.1
Compliant)
• 8/16/32/96 channel 16-bit +/- 10V DACs
• DC-100KHz per D/A throughput
• 2MHz/board maximum update rate
• 1/2/4/8/16/32/64 Fixed/Unlimited channel list length
• Asynchronous/Simultaneous update modes for the all
DACs
• Eight Digital Inputs
• Eight Digital Outputs
• Counters/Interrupt/Synchronization inputs
• Per-channel calibration
• Sense lines for the each DAC (optional), jumper-
selectable on PDXI models
• User-defined Power-Up states for the each DAC (200
ms maximum setup time after the system reset) Default
is 0V.
• Three 24-bit counter timers (16.5/25MHz maximum)
• On-board 2K FIFO (located in the DSP memory)
• 32Ksamples FIFO upgrade option
• Software:
PowerDAQ for
Windows95/98/Me/NT/2000/XP/Linux/QNX
Visual C++, VB, Delphi, C++ Builder, Kylix
Drivers for: LabVIEW®
HP VEE®
LabWindows/CVI®
TestPoint®
DASYLab®
DiaDem®
MATLAB DAQ Toolbox
Note For the full list of specifications,
see Appendix A:
Specifications.
