Chapter 5: Interconnections
3
PD2- AO-96 Connectors
The PowerDAQ PD2-AO-96 boards have seven headers on it:
40-way boxed IDC header – analog output connectors (J3-
J8)
36-way boxed IDC header (DIO/Timer and IRQ lines)
Figure 6: PowerDAQ™ PD2-AO-96 Connectors
Note For manufacturers part numbers,
see Appendix A:
Specifications
.
PowerDAQ(tm) PD-AO-96 board
J2 Connector
J4 Connector
J7 Connector
J3 Connector
J6 Connector
J5 Connector
J8 Connector
Connectors from all cables are going through the
PCI bracket. Following connector layout is defined :
J2- DIO/Timers
J3 - AOut 0..15, J4 - AOut 16..31, J5 - AOut 32..47,
J6 - AOut 48..63, J7 - AOut 64..79, J3 - AOut 80-..95
