Chapter 2: Installation and Configuration
15
Screw Terminal Panels
The PD2-AO-STP-16/32 is a 16/32-channel screw terminal
panel, which also includes connections for the counter
timers, high speed interrupt/synchronization lines and DIO
ports. Using the jumpers, each sense line can be connected
to the appropriate output directly on the screw terminal.
Note For the all PDXI-AO boards, the sense to force line
jumpers are located directly on the board. All jumpers should
be removed from the PD2-AO-STP panel in this case.
Because of compatible pin-outs, the PD-BNC-xx terminals
can be used with PD2-AO-8[16][32] boards. Custom terminal
panels are available. Please contact the factory for more
details.
Figure 3: PD2-AO-STP-32 Wiring Diagram
PD2-AO Board
PD-AO-STP-32
Cable PD-CBL-96
Cable PD-CBL-37
PDXI-AO
board
PD-AO-STP-32
PDXI-CBL-AO
To Next Page
