Chapter 2: Installation and Configuration
14
Analog cable (PD2-AO-96 boards only)
PD-CBL-4037TP: The J3-J8 connector uses a 36-way flat
or twisted pair ribbon cable (DB37 to IDC40)
to bring out the analog output signals. It
connects to: PD-STP-3716, so one PD2-AO-
96/16 board requires a set of six cables and
terminals for all ninety-six channels.
Note The PowerDAQ PD2-AO-8/16/32 boards require a PD-
CBL-96 and the PD2-AO-96 requires up to 6 PD-CBL-4037TP.
If digital IO/CTM is going to be used, an optional PD-CBL-37
cable is required.
Custom cables are available. Please contact the factory for
more details.
Splitter analog/digital cable (PDXI-AO boards
only)
PDXI-CBL-AO: The J1 connector uses a split round
shielded cable, which brings out the analog signals to a 96-
way “pin-less” Fujitsu connector and the digital I/O signals
to 37-way DB-37 connectors.
It connects to: PD2-AO-STP-xx, PD-BNC-xx accessory panels.
