Appendix A: Specifications
43
Appendix A: Specifications
PD2-AO specifications:
The following conditions apply:
T
A = 0°C to +85°C
AO subsystem
Parameter Value
Number of channels 8,16,32 or 96 (PD2-AO only)
Resolution 16 bits
Update rate
100 KS/s channel, up to 1600 KS/s aggregate
throughput in DMA mode, 455 KS/s in unlimited
channel list mode.
Buffer Size
2k samples (upgradeable to 32 KSamples on PDXI-
AO models)
Type of D/A Double-buffered
Accuracy +/- 3 LSB max
DNL +/- 3 LSB max
Monotonicity Over
Temperature
15 bits
Gain Error 0.02% (PDXI-AO), 0.05% (PD2-AO)
Range
+/- 10V fixed, 0..10V factory-installed option
available for PD2-AO-96/16 board
Output Coupling DC
Output Impedance 0.15 Ohm max
Current Drive +/-5mA (PDXI-AO,PD2-AO-96)
+/-20mA(PD2-AO-8[16][32])
Capacitive Loads 180 pF min
Settling time 10uS to 0.003%
Slew Rate 10V/uS
Gain Bandwidth 1 MHz
Noise 2LSB RMS, 0-10000Hz
Output protection Short to ground, +/- 15 Volts
Power-on state, default, user
programmable
0.0000V +/-25mV (PD2-AO-8[16][32]
0.0000V +/-5mV (PD2-AO-96, PDXI-AO)
Gain drift 25ppm/deg C
