Appendix B: Accessories
48
PDXI-CBL-AO:The PDXI-AO J1 connectors use a split 96-
way shielded round 1-meter cable. It
connects to: PD2-AO-STP-xx, PD-BNC-xx
accessory panels. Note, that both analog and
digital signals are connected to the screw
terminal using this cable.
PD-CBL-37: This is a 37-way ribbon connector set. It
comprises of a 13” internal ribbon cable
which connector from the PowerDAQ™ II AO
board J2 internal digital connector
(DIO/Counters/IRQx) to a 37-way D-SUB
bracket. A 1-meter ribbon cable then
connects from the bracket to the PD-AO-STP
accessory panels. The PD-CBL-37 is available
as an option.
PD-CBL-4037TP: This is a 36-way ribbon cable which
connectos from the PowerDAQ™ II AO 96
channel board J3-J8 internal analog
connector to a 37-way D-SUB bracket. A 1-
meter ribbon cable then connects from the
bracket to the PD-STP-3716 accessory panels.
Used with PD2-AO-96 boards only.
