Appendix B: Accessories
51
Terminal
Pin
PD2
[PDXI]-AO-8
PD2-AO-96 Termi
nal
Pin
PD2
[PDXI]-AO-8
PD2-AO-96
1 OUT0 Clk. In. 20 SNS0 Clk.Out
2 AGND Ext. Trig 21 OUT1 DGND
3 SNS1 DGND 22 AGND AGND
4 AGND OUT0 23 OUT2 AGND
5 SNS2 OUT1 24 AGND AGND
6 AGND OUT2 25 OUT3 AGND
7 SNS3 OUT3 26 AGND AGND
8 AGND OUT4 27 OUT4 AGND
9 SNS4 OUT5 28 AGND AGND
10 AGND OUT6 29 OUT5 AGND
11 SNS5 OUT7 30 AGND AGND
12 AGND OUT8 31 OUT6 AGND
13 SNS6 OUT9 32 AGND AGND
14 AGND OUT10 33 OUT7 AGND
15 DNC OUT11 34 SNS7 AGND
16 DNC OUT12 35 DNC AGND
17 DNC OUT13 36 DNC AGND
18 DNC OUT14 37 DNC N/C
19 DNC OUT15 DNC= Do
not connect
To Next Page
