Ultimaker 3 Extended Instruction Manual

3D PRINT - Ultimaker Extended 3 CHAPTER 2. MATERIAL
1 : Rotate button to select the menu - 2 : Push button to confirm
• Select the ”Material 1” and then ”Change”. Select ”Load” when the spool
materials is not installed before.
1 : Menu - 2 : Load option - 2 : Change option.
• Remove the spool guide holder from spool holder towards you.
1 : Spool holder- 2 : Spool guide holder
• Place the material spool on the guide holder. Make sure that the spool
material in counter-clockwise direction.
13

Ultimaker 3 Extended Specifications

General

Build Volume	215 x 215 x 300 mm
Layer Resolution	20 - 200 microns
Print Technology	Fused Filament Fabrication (FFF)
Filament Diameter	2.85 mm
Operating System	Windows, MacOS, Linux
Print Speed	Up to 24 mm³/s
Software	Ultimaker Cura
Weight	11.3 kg
Print Head	Dual extrusion
Nozzle Diameter	0.4 mm
Supported Materials	PLA, ABS, Nylon, CPE, PVA
Connectivity	USB, Ethernet, Wi-Fi
Display	4.7" color touchscreen
Power Requirements	100 - 240 V / 50 - 60 Hz
Travel Speed	Up to 300 mm/s
