Ultimaker 3 Extended Instruction Manual

Chapter 3
Build plate
Make sure that the glass plate is completely clean and free of any materials
and fingerprints. If not, clean the glass plate. Open the two build plate clamps
at the front to secure the glass plate 2 . And then slide the glass plate onto
the build plate 4 .
• Back the glass plate onto the build plate 1 . Close the two build plate
clamps at the front to the glass plate 2 .
17

Ultimaker 3 Extended Specifications

General

Build Volume	215 x 215 x 300 mm
Layer Resolution	20 - 200 microns
Print Technology	Fused Filament Fabrication (FFF)
Filament Diameter	2.85 mm
Operating System	Windows, MacOS, Linux
Print Speed	Up to 24 mm³/s
Software	Ultimaker Cura
Weight	11.3 kg
Print Head	Dual extrusion
Nozzle Diameter	0.4 mm
Supported Materials	PLA, ABS, Nylon, CPE, PVA
Connectivity	USB, Ethernet, Wi-Fi
Display	4.7" color touchscreen
Power Requirements	100 - 240 V / 50 - 60 Hz
Travel Speed	Up to 300 mm/s
