Ultimaker 3 Extended Instruction Manual

3D PRINT - Ultimaker Extended 3 CHAPTER 2. MATERIAL
2.2.1 Material 2
• Go to the menu ”MATERIAL/PRINTCORE” by rotating and then push-
ing the button 1 at the front side of the 3D print.
1 : Rotate button to select the menu - 2 : Push button to confirm
• Select the ”Material 2” and then ”Change”. Select ”Load” when the spool
material is not installed before.
1 : Menu - 2 : Load option - 2 : Change option.
The print core 2 BB 0,4mm is only for PVA material.
• Place the spool material 2 on the spool holder.
9

Ultimaker 3 Extended Specifications

General

Build Volume	215 x 215 x 300 mm
Layer Resolution	20 - 200 microns
Print Technology	Fused Filament Fabrication (FFF)
Filament Diameter	2.85 mm
Operating System	Windows, MacOS, Linux
Print Speed	Up to 24 mm³/s
Software	Ultimaker Cura
Weight	11.3 kg
Print Head	Dual extrusion
Nozzle Diameter	0.4 mm
Supported Materials	PLA, ABS, Nylon, CPE, PVA
Connectivity	USB, Ethernet, Wi-Fi
Display	4.7" color touchscreen
Power Requirements	100 - 240 V / 50 - 60 Hz
Travel Speed	Up to 300 mm/s
