Ultimaker 3 Extended Instruction Manual

3D PRINT - Ultimaker Extended 3 CHAPTER 2. MATERIAL
.
1 : spool holder - 2 : spool material 2.
Make sure that the spool material is in clockwise direction.
.
• Check the shape of the tip of the material. If it doesn’t look good, cut the tip
of the material.
.
• Insert and push the end of the material 2 into the feeder 2. Push the feeder
knob through up 2 and at the same time, pull the material 1 .
.
1 : Feeder enter - 2 : Feeder knob.
• Confirm by pushing the button at the front side of the 3D print when you
have inserted the materiel.
10

Ultimaker 3 Extended Specifications

General

Build Volume	215 x 215 x 300 mm
Layer Resolution	20 - 200 microns
Print Technology	Fused Filament Fabrication (FFF)
Filament Diameter	2.85 mm
Operating System	Windows, MacOS, Linux
Print Speed	Up to 24 mm³/s
Software	Ultimaker Cura
Weight	11.3 kg
Print Head	Dual extrusion
Nozzle Diameter	0.4 mm
Supported Materials	PLA, ABS, Nylon, CPE, PVA
Connectivity	USB, Ethernet, Wi-Fi
Display	4.7" color touchscreen
Power Requirements	100 - 240 V / 50 - 60 Hz
Travel Speed	Up to 300 mm/s
