Ultimaker 3 Extended Instruction Manual

3D PRINT - Ultimaker Extended 3 CHAPTER 2. MATERIAL
.
If you cannot remove the material from the feeder 1 . Push the feeder knob
though up 2 and at the same time, pull the material 3 .
.
• Remove the material from the spool holder 1 .
* For Spool 1 :
Pull the spool holder 2
.
1 : spool material 1 - 2 : spool holder
* For Spool 2 :
Pull the spool holder 1 and then slide the spool material 2 .
7

Ultimaker 3 Extended Specifications

General

Build Volume	215 x 215 x 300 mm
Layer Resolution	20 - 200 microns
Print Technology	Fused Filament Fabrication (FFF)
Filament Diameter	2.85 mm
Operating System	Windows, MacOS, Linux
Print Speed	Up to 24 mm³/s
Software	Ultimaker Cura
Weight	11.3 kg
Print Head	Dual extrusion
Nozzle Diameter	0.4 mm
Supported Materials	PLA, ABS, Nylon, CPE, PVA
Connectivity	USB, Ethernet, Wi-Fi
Display	4.7" color touchscreen
Power Requirements	100 - 240 V / 50 - 60 Hz
Travel Speed	Up to 300 mm/s
