Ultimaker S7 - Main Components

4
78
3
2
1
6 5
9
10
11
12
13
14151617
EN UltiMaker S7 Installation and user manual 8
2.1 Main components
1. Glass door
2. Print head
3. AirManagerlter
4. Bowden tubes
5. Z-stage
6. Flexible build plate
7. Touchscreen
8. USB port
9. Air Manager fan
10. Air Manager cable
11. Feeder 2
12. Feeder 1
13. Spoolholderwithlamentguide*
14. Power socket and switch
15. Ethernet port
16. NFC port
17. UMB OUT port
* Not required in combination with
the Material Station
