EN UltiMaker S7 Installation and user manual 14
Connect the Material Station Bowden tubes
This section describes how to connect the Bowden tubes of the Material Station to the feeders of the
UltiMaker S7. If you do not have a Material Station, skip this section.
1. Insert a tube coupling collet in the bottom of each feeder of the UltiMaker S7.
2. Insert the left Bowden tube of the Material Station into the left feeder, and the right Bowden tube
into the right feeder
3. Secure the Bowden tubes with clamp clips.
Connect the power cable
1. Connect the power cable to the power socket at the back of the printer.
2. Plug the other end of the cable into a wall outlet.
IftheUltiMakerS7isinstalledincombinationwithaMaterialStation,rstconnectthepowerextensioncable.
Connect one side to the printer and the other to the double power entry port of the Material Station. Connect
the power cable to the Material Station and the other end to a power outlet.
3.4 Welcome setup
Toperformthesetupsteps,turnontheprinterwiththepowerswitchattheback.Youwillrstbeaskedtoselect
your preferred language. After this, the welcome setup will appear on the touchscreen. Follow the steps on the
touchscreen and described on the next pages of this user manual.
The language on the printer can always be changed later. Find this option in the Preferences menu, under
Settings → Language.
Build plate
Inthisstepofthewelcomesetup,youmustconrmthatyouhaveinstalledtheexiblebuildplate.Ifyouhavenot
yet done so, follow the instructions in section 3.3tocorrectlyplacetheexiblebuildplate.
If the build plate is not recognized by the printer, it is not installed correctly. Ensure the plate is fully aligned
with the back of the base plate, so the build plate detection sensor is activated.
