Ultra Power B6 mini User Manual

NIMH/NICD BATTERY PROGRAM
Discharge
current
Battery
type
Battery
voltage
Elapsed
time
Discharged
capacity
NiMH 0.1A 7.42V
DSC 022:45 00890
The screen indicates the discharging state.
you can press START/ENTER button to
alter discharge current, Press START/
ENTER button again to store the value,
Press BATT TYPE/STOP button to stop
discharging. The emitted sound alerts the
end of discharging.
You can set up sequence on the left and
the number of cycles on the right. Range
of the cycle number is 1-5.
Press BATT TYPE/STOP button to stop
program, you can press START/ENTER
button to alter charge current, the sound
indicates the end of program.
CHARGE/DISCHARGE & DISCHARGE/CHARGE CYCLE OF
NIMH/NICD BATTERY
-
+
-
+
Battery
type
Elapsed
time
Battery
voltage
Discharged
or charged
capacity
Discharge
or charge
current
NiMH CYCLE
CHG＞DCHG 1
NiMH 1.0A 7.42V
C>D 022:45 00890
Start
Enter
Batt type
Stop
>3 seconds
DEC. INC. DEC. INC.
21
