User’s Manual UT5300X+ and UT5320R-SxA Series
30 / 43
Instruments.uni-trend.com
7. File Mangement
This chapter includes the contents as follows.
[Storage]
[Boot-up Recall]
File Operating
7.1 File Managment
When high voltage output is stop, press [Save] key to enter <File> page.
Figure 7-1 <File Management> Page
7.1.1 [Media]
Storage function is select the file from the instrument’s internal or external U flash disk.
The instrument’s internal can access 100 files, U flash disk can asccess 20 files.
7.1.2 [Auto Load]
Boot-up recall function can assign the call file when the instrument is boot-up, it has two options:
file 1 and the current file.
If select the file 1, then load the setting value of file 1 when the instrument is boot-up;
The setting steps:
1. Enter <File> page;
2. Use cursor key to select [Auto load] filed;
3. According to the need to select file 1 or the current file by the function key on the screen.
7.1.3 [File 1] ~ [File 100]
User can assign 1~100 files to save, read and delete.
Save all the settings into the current file.
Read the parameter of the file to the system.
Rename the file name, it can be user-defined.
The Setting Steps:
