5
UTD4000 Four-channel
User Manual
Figure 1-4 Schematic diagram of the display interface
Trigger status display
Displayingthehorizontal triggerposition
Trigger frequency counter
Channel vertical
attenuation range
Trigger level
Waveform
displaywindow
Themenuvaries with
individualfunction keys
Channel vertical
reference
Displaying main
time base setup
