2. Use the horizontal knob to adjust
the horizontal position of the waveform
window. When the horizontal knob is
turned you can see that the waveform moves
horizontally with the knob
3. Press [ ] to activate the display window and
dual time base menu. In this menu press [ ] to
activate window expansion Then press
again to quit window expansion and return to
the main display screen For dual time base
setup press You can also set the
holdoff time with this menu by turning the
Shortcut key for resetting the trigger point to
When the trigger point has shifted significantly away
from the horizontal centre point, use the [POSITION]
knob to quickly reset the trigger point to the
horizontal centre point. You can also use the
horizontal knob for adjustments
means the actual trigger point relative
to the centre point of the storage device. By turning
the horizontal knob you can move the
trigger point horizontally
means time before another
trigger to be accepted. Turn the
control knob to set the holdoff time By adjusting
holdoff time you can observe complex or
